双排180度排针 PH2.54 H1.5 W5.0
产品分类:间距2.54mm
PH2.54排针:
PIN 数:2*2P~2x40P
塑胶高 H:1.0/1.5/2.0/2.5mm
排 数:双排、
折弯类型:180度/90度/SMT
材 质:PBT/PA6T/PA9T/LCP
四 方 针:0.64mm
详细介绍
![](/image/pdf.png)
![](/image/dowm.png)
Material:
Contact Material: Brass
Contact plating: Au or Sn Over30-50u" Ni
Insulator Material: Black Polyester UL94V-0
Standard: PA6T/PA9T/LCP+30%G.F
Electrical:
Current rating: 3.0Amps/contact max.
Contact resistance: ≤20mΩ/contact
Insulation resistance: ≥1000MΩ at V=100V
Withstanding Voltage: 1000V AC/minute
